Arculus Surface anti-ligature is a luminaire suitable for secure health environments.
- Designed to meet the requirements of “Design in Mental Health Network’s (DiMHN) Testing Guidance for Products in Mental Health Facilities”
- Anti-ligature design to help prevent self harming.
- Designed to be disassembled and reinstated to ensure maintenance can be undertaken quickly and easily after anti-pick mastic application.
- Discreet side mounted fixing gives a clean, unobtrusive aesthetic.
- Opal diffuser gives soft lit appearance while providing functional light for tasks.
- Impact resistance rating: IK16 (150 joules of energy).
- Ingress protection rating: IP65.
- Suitable for mounting on any ceiling which can hold the required weight.
- Robust zinc coated steel body, finished in matt white polyester powder coat.
- Electronic control gear on removable tray with fused plug & socket connector block.
- Supplied with flying lead.
|LED, Opal Diffuser||Temp||Load||Lum/lm||Efficacy||CRI||Weight|
|L628mm x W628mm x H100mm|
|ARC-2000N-MW||4000K||17.5 W||2189lm||125 lm/W||CRI>90||14.4kg|
|ARC-3000N-MW||4000K||24.8 W||3190lm||129 lm/W||CRI>90||14.4kg|
|ARC-4000N-MW||4000K||34.2 W||4373lm||128 lm/W||CRI>90||14.4kg|
|ARC-2000W-MW||3000K||17.6 W||2137lm||121 lm/W||CRI>90||14.4kg|
|ARC-3000W-MW||3000K||24.9 W||3075lm||123 lm/W||CRI>90||14.4kg|
|ARC-4000W-MW||3000K||34.4 W||4238lm||123 lm/W||CRI>90||14.4kg|
Arculus Surface contains a light source of energy efficiency class C (4000K) and class D (3000K).
Arculus Surface LED Lifetime L80B10>72,000h at 25oC ambient.
Arculus Surface Driver Lifetime up to 100,000h at 25oC ambient.
|Titanium finish||replace MW with MT|
|Integral 3-hour duration emergency||add suffix -E3|
|Self test 3-hour duration emergency||add suffix -ES|
|DALI 3-hour duration emergency||add suffix -ED|
|DALI dimming/monitoring||add suffix -DA|
